MIG-D  Inverter

MIG-D Inverter

DESCRIPTION:

● Inverter technology IGBT switches, portable design and energy saving.

● Single phase power input, DC output, suitable for gas or gasless welding process.

● Multifunctiton for MMA welding and MIG/MAGwelding process, strong wire feeder built-in.

● Digital display for current and voltage.

● Stepless regulation for welding voltage and wire speed, automatic protection for over heat and over current.

● Easy arc starting, excellent welding performance ,deep welding pool, low noise, little splash.

OPTIONAL:

● MMA Function

0
Views: 2,543

Details

Model

MIG-140D

MIG-160D

MIG-200D

MIG-220D

Rated Input Voltage (V)

230

230

230

230

No-load Voltage (V)

56

56

56

56

Current Range (A)

40-140

40-160

40-200

40-220

Fuse (A)

16

18

20

25

Duty Cycle (%)

60%

60%

60%

60%

Max Spool Diameter(mm)

200

200

200

200

Max Wire Diameter (mm)

0.8

1.0

1.0

1.0

Weight (Kg)

12.5

13

13.5

15
