MIG-S  Inverter

MIG-S Inverter

DESCRIPTION:

● Inverter technology IGBT( module) switches,portable design and energy saving.

● Three phase power input, DC output.

● Multifunctiton for MMA welding and MIG/MAG welding process, wire feeder built-in.

● Precision regulation for voltage, current, and inductance.

● Digital display for current and voltage, automatic protection for over heat and over current.

● Burn back time is automatically adjusted according to the wire used.

● With 2T/4T gun switch latching, moving wheels.

● Easy arc starting, excellent welding performance, deep welding pool, low noise, little splash.

OPTIONAL:

● MMA Function

0
Views: 973

Details

Model

MIG-300S

MIG-350S

MIG-500S

Rated Input Voltage (V)

400

400

400

No-load Voltage (V)

56

62

65

Current Range (A)

40-300

40-350

40-500

Fuse (A)

25

28

32

Duty Cycle (%)

60%

60%

60%

Max Spool Diameter(mm)

300

300

300

Max Wire Diameter (mm)

1.2

1.6

1.6

Weight (Kg)

24

38

45
